Dayton
/ Sterling QVF Gas Unit Heater Information
(for propane and natural gas heaters)
Back to Sterling Heaters
Pricing Page
Heat Exchanger
Airfoil contoured dimpled tubes allow expansion and contraction stresses to flow
out evenly across the heat exchanger tubes. There are no ridges or sharp bends
in the tubes where stresses can concentrate to cause early heat exchanger failure
through metal fatigue. Operational noises during warm-up and cool down are also
minimized by the tube design. Heat exchangers are die formed from corrosion and
rust resistant 20 gauge aluminized steel.
Burner
Corrosion resistant aluminized steel with
slotted, oversized ports and stainless steel separator strip to help prevent clogging
and reduce maintenance. Sterling's ribbon style burners are unique because multiple
burners are used for each heater. This feature greater reduces replacement cost
and installation time if one stops working properly.
Enclosure
Aluminized steel with
baked-on gray powder paint finish. Hinged bottom pan allows access to burner and
pilot assembly. Removable side panels enables maintenance and suspension point
adjustment.
Standard Controls
115 volt power supply and 25 volt controls. Limit control shuts off main burner
to prevent overheating. Single stage standing pilot ignition with safety redundant
gas valve. 100% safety shut-off.
Additional Dayton / Sterling QVF Gas Unit Heater
Information
Download
Dayton / Sterling QVF Gas Heater Installation Manual
Heat Throw (ft)
|
33
|
33
|
33
|
40
|
60
|
70
|
90
|
Flue Type - R = Round; OV = Oval; H = Horizontal; V
= Vertical |
Gas Connections - natural gas may vary depending on
control availability. |
Clearances to Combustibles
Top |
6"
|
Bottom |
12"
|
Sides |
18"
|
Rear |
18"
|
Do not use QVF units with duct work. |
It is recommended that all gas heaters be installed by a qualified
installation and service contractor. |
Ratings shown are for elevations up to 2,000 feet above sea
level. For elevations above 2,000 ft., ratings should be reduced by approximately
4% for each 1,000 ft. above sea level. |
